| 3003 Aluminum Coils | |||
|---|---|---|---|
| The 3003 Aluminum Coil is a versatile, non-heat-treatable alloy from the 3xxx series, renowned for its excellent formability, moderate strength, and superior corrosion resistance. Composed primarily of aluminum (98.6%), manganese (1.0–1.5%), and trace copper (0.05–0.20%), this alloy offers enhanced mechanical properties compared to pure aluminum while retaining exceptional workability. It is widely used in applications requiring shaping, welding, or brazing, such as HVAC systems, chemical equipment, roofing, and automotive trim. Available in multiple tempers (e.g., H14, H18), the coil is ideal for environments exposed to moisture or mild chemicals. Its non-sparking nature and lightweight properties make it suitable for industrial and architectural uses. | |||
| Parameters | |||||||
|---|---|---|---|---|---|---|---|
| Product Name | 3003 Aluminum Coil | ||||||
| Product Type | Aluminum / Aluminum Coil | ||||||
| Material Standard |
| ||||||
| Temper Options | O (Annealed), H14, H18, H22, H24 | ||||||
| Thickness | 0.2 mm – 6.0 mm | ||||||
| Width | 100 mm – 2000 mm | ||||||
| Inner Diameter | 150 mm, 300 mm, 505 mm, or custom | ||||||
| Outer Diameter | Up to 2000 mm | ||||||
| Coil Weight | Up to 10,000 kg | ||||||
| Surface Finish |
| ||||||
| Certifications | ISO 9001, RoHS, REACH | ||||||
| Applications |
| ||||||
| Advantages |
| ||||||
| Limitations | Not suitable for high-stress structural applications (use 6061-T6 instead) | ||||||
| Chemical Composition | |||||||
|---|---|---|---|---|---|---|---|
| Aluminum (Al) | Manganese (Mn) | Copper (Cu) | Iron (Fe) | Silicon (Si) | Zinc (Zn) | Other Elements | |
| Balance (≥98.6%) | 1.0–1.5% | 0.05–0.20% | ≤ 0.7% | ≤ 0.6% | ≤ 0.10% | ≤ 0.15% total | |
| Mechanical Properties | |||||||
|---|---|---|---|---|---|---|---|
| Temper Options | Temper O | Temper H14 | Temper H18 | ||||
| Tensile Strength | 110 MPa (16 ksi) | 150 MPa (22 ksi) | 185 MPa (27 ksi) | ||||
| Yield Strength | 40 MPa (6 ksi) | 140 MPa (20 ksi) | 170 MPa (25 ksi) | ||||
| Elongation | 30% | 8% | 4% | ||||
| Physical Properties | |||||||
|---|---|---|---|---|---|---|---|
| Density | Melting Point | Thermal Conductivity | Electrical Conductivity | ||||
| 2.73 g/cm³ | 643–654°C (1190–1210°F) | 163 W/m·K | 40% IACS | ||||
