| 1050 Aluminum Coils | |||
|---|---|---|---|
| The 1050 Aluminum Coil is a commercially pure aluminum product (99.5% minimum aluminum content) renowned for its exceptional formability, high thermal/electrical conductivity, and superior corrosion resistance. Part of the 1000 series, this alloy is soft, ductile, and lightweight, making it ideal for applications requiring intricate shaping or bending without compromising structural integrity. Its non-heat-treatable nature ensures consistent performance in environments where electrical efficiency, heat dissipation, or resistance to oxidation is critical. Available in various tempers (O, H12, H14, etc.), thicknesses (0.2–6 mm), and widths (100–2000 mm), the 1050 coil is widely used in electrical components, reflectors, chemical equipment, and decorative finishes. Surface options include mill finish, anodized, or coated treatments. Manufactured to ASTM/ISO standards, it combines cost-effectiveness with sustainability, as it is fully recyclable. | |||
| Parameters | |||||||
|---|---|---|---|---|---|---|---|
| Product Name | 1050 Aluminum Coil | ||||||
| Product Type | Aluminum / Aluminum Coil | ||||||
| Material Grade | UNS A91050, EN AW-1050A | ||||||
| Thickness | 0.2 mm to 6 mm (±0.02 mm tolerance) | ||||||
| Width | 100 mm to 2000 mm (±1 mm tolerance) | ||||||
| Inner Diameter | 150 mm, 300 mm, 505 mm, or 600 mm | ||||||
| Outer Diameter | Up to 2500 mm (customizable) | ||||||
| Surface Treatments |
| ||||||
| Standards Compliance | ASTM B209, EN 573-3, ISO 209, AMS 4003 | ||||||
| Key Applications |
| ||||||
| Optional Features |
| ||||||
| Chemical Composition | |||||||
|---|---|---|---|---|---|---|---|
| Aluminum (Al) | Iron (Fe) | Silicon (Si) | Copper (Cu) | Manganese (Mn) | Zinc (Zn) | Other Trace Elements | |
| ≥ 99.5% | ≤ 0.40% | ≤ 0.25% | ≤ 0.05% | ≤ 0.05% | ≤ 0.07% | ≤ 0.03% each. | |
| Mechanical Properties | |||||||
|---|---|---|---|---|---|---|---|
| Temper Options | O (Annealed) | H12/H14/H16/H18 (Strain-Hardened) | |||||
| Tensile Strength | 60–95 MPa | 70–130 MPa (increasing with hardness) | |||||
| Yield Strength | (0.2% Offset): 15–35 MPa | 30–120 MPa | |||||
| Elongation | 25–30% | 10–20% (decreases with hardness) | |||||
| Physical Properties | |||||||
|---|---|---|---|---|---|---|---|
| Density | Melting Point | Thermal Conductivity | Electrical Conductivity | ||||
| 2.71 g/cm³ | 640–660°C | 222 W/m·K | 61% IACS (International Annealed Copper Standard) | ||||
