Stainless Steel U Channel

Name: Stainless Steel U Channel - Erikco World
Brand: Stainless Steel Channel

Stainless Steel U Channels are corrosion-resistant structural profiles with a U-shaped cross-section, ideal for construction, marine, and industrial applications. Available in grades 304/316, customizable sizes, and finishes.

Category Stainless Steel Channel

Rating:

Stainless Steel U Channel
A Stainless Steel U Channel is a structural profile with a U-shaped cross-section, featuring two parallel vertical legs (flanges) connected by a horizontal base (web). It is manufactured from corrosion-resistant stainless steel grades (e.g., 304, 316) using hot rolling, extrusion, or cold forming. This profile excels in applications requiring durability, hygiene, and resistance to harsh environments. Common uses include construction frameworks, machinery supports, marine components, and architectural trim. Customizable in dimensions, thickness, and surface finish (mill, brushed, polished), it adheres to ASTM/AISI standards. Optional treatments like passivation or powder coating enhance performance in specialized settings.

Parameters
Product Name	Stainless Steel U Channel
Product Types	Stainless Steel / Stainless Steel Channel
Material Grades	Grade 304: General-purpose, excellent corrosion/oxidation resistance. Grade 316: Superior corrosion resistance (Mo-added), ideal for marine/chemical environments. Other grades: 201, 430, 410 (upon request).
Standard Sizes (Base × Leg × Thickness)	20×10×1.5mm to 200×100×10mm (customizable)
Thickness Range	1.5mm – 12mm
Length	Standard 6m, customizable up to 12m
Certifications	ISO 9001, Material Test Reports (EN 10204 3.1/3.2)
Standards	ASTM A554 (structural tubing), ASTM A480 (sheet/plate). EN 10088-2 (EU standards).
Tolerances (ASTM A484)	Thickness: ±0.1mm. Straightness: ±1mm per meter. Length: ±5mm.
Customization Options	Cutting, drilling, notching, welding. Bespoke dimensions and finishes.

Mechanical Properties
Tensile Strength	Yield Strength	Elongation	Hardness
515 MPa (304/316)	205 MPa (304/316)	40–45%	85 HRB (max)

Packing and delivery
These Product are packed using seaworthy export packaging to ensure protection during transit. Each coil is wrapped with waterproof paper, plastic film, and steel sheet, secured with high-tensile steel straps, and placed on wooden pallets for stability. Edge protectors are used to prevent damage. These Product are safely loaded for efficient domestic and international delivery, ensuring they arrive in perfect condition.

FAQs

How long does your delivery time take?

Generally, our delivery time is within 7-45 days, if there is a great demand or special circumstances, it may be delayed.

How could you guarantee your products?

Each piece of products is manufactured by certified workshops, inspected by Linxu piece by piece according to national QA/QC standard. We also could issue the warranty to customer to guarantee the quality.

Do you accept the third party inspection?

Yes absolutely we accept.

Do you provide samples ? Is it free or extra ?

The sample could can provide for customer with free, but the courier freight will be covered by customer account.

Will you delivery the goods on time?

Yes, we promise to provide best quality products and delivery on time. Honesty is our company’s tenet.

Are you trading company or manufacturer ?

We are professional manufacturer with rich experience, and our company also is a very professional a trade company for steel products. We can also provide a wide range of steel products.
